Ceramic-Coated Doctor Blades

video
product name

L Doctor Blade

Width Range: 10mm-60mm

Width Tolerance: ±0.1mm

Thickness Range: 0.152mm-0.203mm

Thickness Tolerance: ±0.005mm

Hardness: 780-810HV

Tensile Strength: 1850-2100Pa

Machine Speed: ≤ 350 m/min

Coating thickness: 6-8um



Blade Edge  Shapes



1-2-carbon-steel-doctor-blades_icon01_副本.jpgLamella Blade Edge1-2-carbon-steel-doctor-blades_icon03_副本.jpgBevel Blade Edge



Key attributes

core componentsbladewarranty3 months
brand namedekeerplace of originAnhui, China
type

Doctor Blade

Product nameL Doctor Blade
ApplicationGravure printing, Flexo printing, Roller Coating, Adhesive coatingMaterialCarbon Steel
Ink TypesWater based ink, UV ink, Corrosive inks with high pH and Ink containing fine metal particles


Packaging and delivery

Selling UnitsSingle itemSingle package size25X25X30 cm
Single gross weight10.000 KG





Features

The addition of ceramic coating and precisionpolished edges extend service life,10 times more curable thanstandard carbon steel blades.


This series of scrapers are made of ZAPP carbon steel from Germany and have a specialceramic coating with a thickness of 6-8um, which enhances wear resistance and extendsservice life.
